HH MOUNTS
IN STOCK
Complete kit to move satellite antennas from 0.6 to 4 meters!
VU +
Peruvision online store (webshop)
Antennas, LNBs, Positioning and Actuators
Actuators, positioners, H-H mounts, Positioner, All products
Positioner VBOX III
The V-BOX III positioner is ideal for controlling all types of actuators
99 programmable memory positions
Supports DiseQc 1.0 and 1.2 commands
Display with multicolored LEDs
Quick reset of all satellites
More protections
SKU: P7788
Antennas, Gibertini satellite dish, All products
GIBERTINI OP 150 S antenna with polar mount
CAN BE SENT BY COURIER
Designed for demanding customers and for geographic areas at the limit of satellite coverage, for centralized system or for motorized installations
The reflector is in aluminum alloy powder coated with UV inhibited polyester-based finishes in RAL7035 (light gray) color
Az / El mount is made of dual sided zinc plated steel and powder painted in the same color
Stainless steel harness
Die-cast aluminum LNB holder
1.50 m AL satellite dish
Frequency range (GHz) 10.00-13.00
Outside dimension (cm) 155.0 x 166.0
Reflecting dimension (cm) 150.0 x 161.0
Illumination efficiency (¹) (%) 70
Gain (¹) @ 10.70 GHz (dB) 43.00
Gain (¹) @ 11.70 GHz (dB) 43.70
Gain (¹) @ 12.75 GHz (dB) 44.50
Cross polarization (¹); (²) on axis (dBc) -28
First side lobe level (¹); (²) (dBc) -25
Noise temp. (¹) @ 12GHz, 30 ° elevation (K) 31
F / D radio 0.66
-3 dB Beam width (¹) @ 11.7GHz 1.07 °
Offset pointing angle 21.3 °
Feed illumination angle 70 °
Feeder clamp (mm) 40
Elevation angle 20 ° - 90 °
Mast clamp (mm) 55 - 100
Reflector thickness (mm) 2.0
Wind-load @ 120 km / h (kg) 250
Antenna net weight (kg) (³) 23.8
Working temperature -30 ° / + 70 °
Humidity 0-100%
SKU: n/a
LNB (LNC), LNB (LNC) offset, All products
LNC INVERTO Twin Black Ultra Punishment-High Noise-Reduced OFF
LNB (LNC), LNB (LNC) offset, All products
LNC INVERTO Twin Black Ultra Punishment-High Noise-Reduced OFF
Input frequency range:
Low bandwidth: 10.7 ~ 11.7 GHz
High band: 11.7 ~ 12.75 GHz
Output frequency range:
Low bandwidth: 950 ~ 1950 MHz
High band: 1100 ~ 2150 MHz
OL frequency:
Low bandwidth: 9.75 GHz
High bandwidth: 10.6 GHz
Own noise: 0.2 dB typical
OL initial accuracy: +/- 1.0 MHz Max.
Phase noise (at 10 kHz): - 90 dBc / Hz Max.
Conversion gain: 60 dB Min.
Conversion point 1 dB (output): 0.0 dBm Min.
Control signal:
Vertical: 11.0 ~ 14.0
Horizontal: 16.0 ~ 20.0 V
Band change: 22 +/- 4 kHz
Current consumption: 180 mA Max. at 11 ~ 20 V.
Operating temperature: - 30 ° C ~ + 60 ° C
Output impedance 75 Ohms
Output connector: type-F (female)
Diameter: 40 mm
Weight: 181g
SKU: L5912
Antennas, Mobile antenna, All products
Caravanman 85 Professional GPS V2
Robust and powerful satellite dish.
The best quality TV and radio reception in Europe.
Smart controller with free application for firmware updates and satellite selection.
GPS receiver and automatic diversion.
Connection for 2 participants and only 20 cm high when withdrawn.
SKU: A7758
Actuators, Actuators, positioners, H-H mounts, All products
Professional actuator Summit ST045-36 (45cm)
Actuators, Actuators, positioners, H-H mounts, All products
Professional actuator Summit ST045-36 (45cm)
Opening: 45 cm
Voltage: 36V DC
Current consumption: 2.5A (at maximum load)
Protection class: IP65
Push the maximum dynamic load: 600 kg
Pull the maximum dynamic load: 600 kg
Maximum static load: 1500 kg
Speed: 1mm / sec (at maximum load); 3mm / sec (no load)
Cycle: max. 10% (maximum 2 min within 18 min at maximum load
Otherwise, the engine overheats!)
SKU: A7569
Antennas, Professional satellite dishes, All products
Skyware Global antenna off 180 fiberglass
ASK FOR A PRICE!
180 Receive Only fiberglass offset antenna (reinforced with polyester), Ku band, with Az / El mount and original Feedhorn
RF performance:
Effective opening: C-band: 1.8 m (71 in), Ku-band: 1.8 m (71 in);
Operating frequency: C-band: 3.7 - 4.2 GHz, Ku-band: 10.95 - 12.75 GHz;
Polarization: C-band: Linear (Circular Optional), Ku-band: Linear (Circular Optional);
Castig @ 3.95 / 11.95 GHz: C-band: 35.3 dBi, Ku-band: 45.5 dBi;
3 dB Beamwidth: C-band: 3.0˚, Ku-band: 1.0˚
Antenna Noise Temperature @ 30˚ Elevation: C-band: 36˚ K, Ku-band: 31˚ K;
VSWR *: C-band: 1.4: 1, Ku-band: 1.3: 1 (depending on LNB)
Antenna Cross Polarization: C-band: 30 dB on Axis (Linear), Ku-band: 30 dB on Axis (Linear);
Feed Interface: C-band: CPR-229, Ku-band: WR75 Flat Flange;
Mechanical performance:
Reflective material: Polyester reinforced fiberglass;
Antenna Optics: One-Piece Offset Feed Prime Focus;
Frame type: .EZ / AL;
Elevation adjustment from: 10˚ - 90˚ continuously;
360˚ continuous azimuth adjustment ± 10˚;
Mast Pipe Interface: 114 mm (4.50 in) Diameter;
Maximum wind speed during operation: 80 km / h (50 mph);
Maximum speed at which the antenna can withstand: 200 km / h (125 mph);
Operating temperatures: -50˚C to 80˚C;
Humidity: 0 to 100% (Condensing);
Atmosphere: Standard Hardware Meets 500 Hour;
Salt Spray Test Requirements
(ASTM B-117)
Solar Radiation: 360 BTU / h / ft2;
ONLY ON ORDER
TRANSPORTATION IS NOT INCLUDED
SKU: n/a
Antennas, Satellite dish parabola, All products
Parabola 2.2m Al MP
Aluminum Prime Focus antenna, diameter 2.2 m, polar mount
Diameter (D) 220 cm
11.350 GHz 46.5 dB gain
12.125 GHz 46.8 dB gain
Gain at 12,626 GHz 47.1 dB
DELIVERY COST IS SEPARATE AND IS CALCULATED ACCORDING TO LOCATION (SPECIAL TRANSPORT)!
SKU: n/a
Receivers
Satellite receivers, Linux receivers, Receivers, IP / OTT Boxes, CAM, All products
VU + DUO 4K SE
Utmost speed and powerful 2.1GHz Quad Core CPU
1 x Smartcard Readers (Xcrypt)
2 x Common Interface
4K UHD Hardware Decoding
2 x Pluggable for FBC (Full Band Capture) DVB-S / S2X (sold with 1 FBC tuner included)
or FBC DVB-C / C V2
or Dual DVB-T2 (MTSIF) Tuner System (up to 8 tuners supported)
2GB LPDDR4 RAM and 4GB eMMC Flash Memory
SKU: R7624
Satellite receivers, Linux receivers, Receivers, IP / OTT Boxes, CAM, All products
PULSE 4K 2x DVB-S2X tuner
Satellite receivers, Linux receivers, Receivers, IP / OTT Boxes, CAM, All products
PULSE 4K 2x DVB-S2X tuner
Processor - Quad core, 15,000 DMIPS
Flash - 8GB EMMC
RAM - 2GB DDR4
Tuner - 2x DVB-S2X
Video decoding - 4K x 2K @ 60 10-bit decoding HDR / HDR10 and HLG
Transcoding - Multi Transcoding & Multiroom Support
HDD - Slot for 2.5 hdd, max. 15 mm
SKU: R7705
Satellite receivers, Receivers, IP / OTT Boxes, CAM, All products
Golden Interstar ALPHA X (Multistream)
Satellite receivers, Receivers, IP / OTT Boxes, CAM, All products
Golden Interstar ALPHA X (Multistream)
Golden Interstar ALPHA X (Multistream)
DVB-S2 and S2X H.265 Full HD digital receiver
Receiver with multistream tuner and Linux-based operating system
Technical specifications:
DVB-S2 multistream tuner
H.265 / HEVC - HD and SD resolution
High resolution OSD menu
BlindScan function with support for low symbol rate
SKU: R1003038
Satellite receivers, Linux receivers, Receivers, IP / OTT Boxes, CAM, All products
VU + Zero 4K (multistream)
Satellite receivers, Linux receivers, Receivers, IP / OTT Boxes, CAM, All products
VU + Zero 4K (multistream)
Utmost speed and powerful 1.5 GHz Dual Core 7000 DMIPS
1 x Common Interface
1x Smartcard readers (Xcrypt)
4K UHD Hardware Decoding
1x DVB-S2X (multistream)
4GB eMMC Flash memory
2GB DDR4
1 x Ethernet
SKU: R7260
Combo receivers, Cable receivers, Satellite receivers, Terrestrial receivers, Receivers, IP / OTT Boxes, CAM, All products
Golden Media WIZARD HD VOTE 3 (H265)
Combo receivers, Cable receivers, Satellite receivers, Terrestrial receivers, Receivers, IP / OTT Boxes, CAM, All products
Golden Media WIZARD HD VOTE 3 (H265)
DVB-S2 + T2 / C Full HD Twin / Combo Receiver (H.265 / HEVC)
1 x Conax Card Reader and 1 x Common Interface (CI Slot for CAMs)
Full HD 1080p receiver, 1080p, 1080i, 720p, 576p, 480p, 576i, 480i video resolution
H264 video decoding but also H265 / HEVC
Supports DiSeCq 1.0, 1.1, 1.2, supports motors for USALS and DiSeCq 2.0 antennas
Support for universal LNB, Easy Find and Unicable Ready
Automatic channel search, Blind Scan function and network search
HDMI output, SCART output and digital audio output (optical)
SKU: R7506
Cable receivers, Receivers, IP / OTT Boxes, CAM, All products
SKYMASTER XC1-LITE
DVB-C Full HD receiver
MPEG4 / H.264 hardware decoding
1 x USB 2.0 port
Video resolution: Full HD 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Image aspect: 4: 3, 16: 9
EPG, OSD multilingual support
Low power consumption in Standby mode
Quick change of programs
SKU: R7501
Networking
Networking and surveillance, Wireless routers, All products
TP-Link Archer AX20 Wi-Fi 6
Wi-Fi performance 6 - Archer AX20 is equipped with Wi-Fi 6 wireless technology, for faster speeds, higher capacity and reduced network congestion
Speeds up to 1.8 Gbps - The Archer AX20 Dual-Band Router reaches even faster speeds of up to 1.8 Gbps (1201 Mbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band)
Connect dozens of devices - Wi-Fi 6 technology transmits more data to multiple devices, using revolutionary OFDMA technology, while reducing lag
Quad-Core Processor - The 1.5 GHz Quad-Core processor ensures communication between the router and all connected devices, providing seamless connections
Enlarged coverage area - Beamforming technology, independent FEM and four antennas provide Wi-Fi signal for connected devices, even remotely
Protects the battery of connected devices - Target Wake Time technology reduces the power consumption of devices connected to the router to extend the life of their batteries *
WPA3 security - The latest Wi-Fi security protocol, WPA3, brings new features to improve personal network cybersecurity
USB sharing - The USB 2.0 port allows easy sharing of files on the network or private storage in the cloud
Gigabit Ports - Connect to devices using a wired network for better stability
Parental control - URL filtering and time controls
Easy setup - Set up the router in minutes with the TP-Link Tether application
Compatibility - Supports all previous 802.11 standards and all Wi-Fi devices
SKU: R7768
Networking and surveillance, Wireless routers, All products
ASUS ZenWiFi AX Hybrid (XP4) WIFI Mesh
Wi-Fi Mesh ASUS ZenWiFi AX Hybrid (XP4), AX1800, Dual-band, Gigabit, Quad-core processor, Whole-Home Coverage, AiProtection, OFDMA, MU-MIMO, Alexa, 2 pieces, white
WiFi 6 - True 8K Streaming
Coverage throughout the house
Ideal for overcoming thick walls
HomePlug AV2 MIMO ensures high bandwidth
Intelligent and flexible backhaul configuration
Works with any WiFi device
AiProtection Classic with Parental Controls is free for life. It gives you total peace of mind and you can check everything that happens in your network through the mobile application.
ASUS ZenWiFi AX Hybrid works perfectly with smart home services - including Alexa capabilities.
AiMesh technology
SKU: M7774
Networking and surveillance, Switches, All products
Switch D-Link DGS-105 (5 x 10/100/1000)
5 RJ45 × 10/100/1000 Mbps ports with Auto-Negotiation that supports Auto-MDI / MDIX;
Green Ethernet technology automatically adjusts power consumption based on connection status and cable length;
IEEE 802.3X flow control ensures reliable data transfer;
Plug and play, no configuration required;
Quiet operation
SKU: S7772
Networking and surveillance, Wireless routers, All products
TP-LINK Archer T2U Nano WIFI adapter
High speed Wi-Fi—Speeds up to 600Mbps, with 200Mbps in the 2.4GHz band and 433Mbps in the 5GHz band.
Wireless Dual Band—2.4 GHz and 5 GHz for flexible connection; upgrade your devices to work with the latest dual band Wi-Fi adapter for higher speed.
Nano design—The minimalist and discreet design allows you to use it without realizing that it is there
Advanced security—Supports 64/128-bit WEP, WPA / WPA2 and WPA-PSK / WPA2-PSK
Supports the latest operating systems—Compatible with Windows 11/10 / 8.1 / 8/7 / XP, Mac OS 10.15 and earlier
SKU: A7771
Networking and surveillance, Wireless routers, All products
TP-Link Archer AX53 Wi-Fi 6
6 Gigabit Wi-Fi speed—2402 Mbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band, ensuring efficient streaming and higher download speeds.
Connect multiple devices—OFDMA technology increases capacity 4 times to allow simultaneous transmissions to multiple devices.
Low latency—Allows uninterrupted gaming sessions and video conferencing.
Extended Wi-Fi coverage—Four high-gain external antennas and Beamforming technology work together to give your home a strong and stable Wi-Fi signal.
TP-Link HomeShield—Improved security protects you from the latest cyber dangers.
Low energy consumption—The Target Wake Time feature allows your devices to communicate more and use less energy at the same time.
Compatible with Amazon Alexa—Control your router with voice commands and live intelligently with Amazon Alexa.
SKU: R7767
Networking and surveillance, Switches, All products
Switch TP-Link TL-SG105 (5 x 10/100/1000)
5 RJ45 10/100 / 1000Mbps Auto-Negotiation ports, supports Auto-MDI / MDIX
Green Ethernet technology for optimized power consumption
The IEEE 802.3x flow control standard provides stable data transfers
Steel housing and design that allows mounting on the desk or wall
Supports QoS (IEEE 802.1p) and IGMP snooping
No configuration required, just plug it in and it's ready to go
SKU: S7769
Networking and surveillance, Wireless routers, All products
TP-Link Archer AX90 WI-FI 6
Wi-Fi AX6600 Tri-Band Quick - 4804 Mbps (5 GHz) + 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz).
Ultra Connection - 1 port 2.5 Gbps WAN / LAN + 1 port 1 Gbps WAN / LAN + 3 Gigabit LAN ports and two USB ports, which ensures maximum flexibility and increased efficiency
Maximized coverage - The eight High-Gain antennas are equipped with Beamforming technology for extended coverage
More devices with less lag - OFDMA and MU-MIMO technologies provide data simultaneously, across multiple devices
TP-Link HomeShield - Increased security protects you against cyber threats
Powerful CPU - The 1.5 GHz quad-core processor ensures fast transmission speeds and uninterrupted operation of many devices and applications
Refined Security—WPA3 strengthens Wi-Fi encryption for enhanced security
SKU: R7806
Networking and surveillance, Wireless routers, All products
TP-Link Deco M4 Wi-Fi Mesh (2-Pack)
Deco uses a drive system to get uninterrupted Wi-Fi coverage for the entire house - eliminating areas with a weak signal forever!
With advanced Deco Mesh technology, the units work together to form a unique network of the same name. The devices automatically switch between units as you move around the house, for the fastest possible speeds.
Deco M4 (2-pack) offers Wi-Fi on up to 260 m2. If that's not enough, you can always add more Deco units to your network to increase coverage.
Deco M4 offers connections with speeds of up to 1167 Mbps and can work on most Internet Service Provider (ISP) connections, including modem connections.
Deco can handle traffic on even the busiest networks, providing seamless connections for up to 100 devices.
Parental control limits online time and blocks inappropriate websites, according to unique profiles created for each family member.
The configuration is easy with the help of the TP-Link Deco application that guides you through each step, the application being available in Romanian
SKU: M7785
CATV headends
CATV headends, All products, WISI
Rack GN 50W Chameleon
Professional rack for CATV WISI Chameleon station with analog and / or digital outputs;
Slots for 10 modules (max. 40 channels DVB-C / 20 DVB-T / 20 PAL B / G, D / K, I / 80 FM);
Includes a built-in Gigabit switch, fan, power supply and connectors;
Designed for applications that require redundancy (optional redundant source).
SKU: n/a
CATV headends, All products, WISI
GNHWUW2 Chameleon module
GNHWUW2 universal module
CHAMELEON - CATV STATION WITH IDENTICAL HARDWARE MODULES
Each Chameleon module contains the following components: universal tuner, universal modulator, CI slot, MPEG decoder, scrambler, PSI / SI generator and a Gigabit / Ethernet interface. These components are integrated twice on each module;
Covers almost all the needs of CATV and SMATV distribution with a single hardware platform;
The various inputs and outputs are defined by software options, which can be updated at any time;
DVB, IPTV and ASI inputs;
Decrypts one or more encodings through CI (Common Interface) interfaces;
Remultiplexes the content from the tuner to IP and ASI level to create your own multiplexes;
Encrypts using the built-in DVB_CSA and Simulcrypt interfaces;
SKU: n/a
CATV headends, All products, WISI
Rack Tangram GT 01 W
TANGRAM WISI RACK, 230 V AC / 48V DC, WITH / WITHOUT SWITCH
Very thin chassis (1RU)
High reliability (carrier grade) with the option to use redundant power supplies
Ease of combining GT modules required for your application
Fans that can be replaced during operation
Modular architecture
SKU: n/a
CATV headends, All products, WISI
WISI OM 10 0648
PLEASE CONTACT US FOR THIS PRODUCT
Transmodulator of 6 DVB-S / S2 transponders to 8 DVB-C or DVB-T channels
The integrated 4 in 6 switch matrix reduces the installation effort and DiSEqC 1.0 is increasing the flexibility by controlling up to 4 satellites
4 CI slots for central decryption
PID remapping allows setting of static service PIDsat the output. It is no longer necessary for the TVset to make a scan if there is any transponder modification at the input
LCN / NIT processing
Multiplex functionality at the input and output
USB - interface to feed in any video content
Programming via web interface
Integrated DHCP server enables an automatic connection to a PC Smartphone and tablet access via Bluetoot
Hotel Mode
SKU: n/a
CATV headends, All products, Transcoding, encoding, monitoring, WISI, WISI
WISI OE 01 DVB-C / T HDMI encoder; ATSC-T / C; DTMB
CATV headends, All products, Transcoding, encoding, monitoring, WISI, WISI
WISI OE 01 DVB-C / T HDMI encoder; ATSC-T / C; DTMB
1 HDMI input supporting all resolutions up to 1080p60.
1 HF loop-through input for feeding into existing DVB-C / T signals
MPEG4 Video compression
Switchable output modulation (DVB-C, DVB-T, DTMB and ATSC-T / C)
Freely adjustable output frequency up to 1218 MHz
User-friendly programming without additional software / hardware
Adjustable NIT / LCN parameters
Compact dimensions and easy assembly
SKU: E7439
CATV headends, All products, Transcoding, encoding, monitoring, WISI, WISI
ENCODER HD / SD SDI SI AV GNHWENC2S Chameleon
CATV headends, All products, Transcoding, encoding, monitoring, WISI, WISI
ENCODER HD / SD SDI SI AV GNHWENC2S Chameleon
HD / SD MPEG-4 (AVC, H.264) and HD / SD MPEG-2 video encoding Up to 4 HD / SD-SDI or A / V analog inputs per module
Professional multiplexer integrated
SPTS and MPTS streaming (CBR or VBR)
Supports PSI / SI processing
Integrated into the CHAMELEON Systemmanagement
Control and management via web-UI
SKU: n/a
CATV headends, All products, WISI
Basic rack LX 50 Optopus
10-module rack for WISI Optopus station;
High density platform, very flexible, for all types of analog optical networks: HFC (hybrid), RFoG (RF by Fiber Optic) or RF Overlay in FTTH applications;
14 slots in a 3 + 1 RU housing (rack units);
Simple connection of modules, power supplies, management modules and fans;
Mechanical integration infrastructure for optical and RF connectors;
Electrical integration infrastructure for management and power supplies;
Designed for total redundancy of power supplies;
Management mode for local and remote surveillance;
Optional LX52 for 2 modules;
SKU: n/a
CATV headends, All products, WISI
Rack OH50A
PLEASE CONTACT US FOR THIS PRODUCT
Basic rack for analog and digital TV signals
Slots for 14 modules (28 digital channels)
19 ”rack or wall mounting
Integrated FM amplifier
Simple programming with OH 41 programming unit (OK 41 A)
Update and pre-programming via USB stick
Remote monitoring mode OH 51
High output power
High efficiency
SKU: n/a
Measuring Devices
Other, Measuring devices, All products
AB CryptoBox Meter (Ideal for camping / truck)
Satfinder DVB-S / S2 ideal for those who want a precise and fast adjustment
Recommended for camping or for shooting drivers
Frequency range: 950MHz ~ 2150MHz
2.4-inch color LCD screen
Spectrum analysis function
BER, MER and Constellation
It supports up to 100 satellites and 4000 transponders
Frequency Margin: 950MHz ~ 2150MHz
Supports: DiSEqC 1.0 / 1.1 / 1.2 / USALS and Unicable1.0 / 2.0 / Digiturk MDU
RF input & output F Male Connector, 75Ω
Flashlight with strong light
Battery running time 2.5 hours
Protective rubber cover
SKU: A7384
Measuring devices, Inverto, All products
Invert SatPal
The SatPal ™ unit, together with the SatPal ™ application, is an antenna installation tool.
It allows installers and DTH operators to control the quality of antenna installations.
A professional Sat Meter and a unique installation system that generates detailed reports at the click of a button.
Satellite frequency range (LNB / Multiswitch) - 950 MHz ~ 2150 MHz 2.4 GHz;
Wireless connection - 2.4 GHz;
LNB / Multiswitch - 1xSatellite IF, 13 V / 18 V DC output, 0 kHz / 22 kHz, type F;
Receiver - 1x satellite IF loop-through output, 13 V / 18 V DC input, type F;
PC (data) - 1x PC data communication, micro USB;
Wireless - 1x IEEE 802.15.1 Low Energy (ver. 4.0);
Power supply - 1x DC input, micro USB;
SKU: A7274
Other, Measuring devices, All products
Megasat Satmeter HD 5 Combo (S / S2 / S2X, C / C2, T / T2)
5 inch (12.7 cm) AMOLED color screen
Optical and acoustic display of the signal level
DVB-S / -S2 / -S2X, DVB-T / -T2, DVB-C / -C2
Integrated speaker for TV playback
USB port for firmware updates, transponder list storage and measurement data
AV input for various equipment (eg cameras)
12 V DC output (for cameras)
Automatic power and standby switch
Power supply: AC 100-2 A, DC 240 V, 2 A
Li-Ion battery (7.4 V / 5000 mA / h)
SKU: A7277
Measuring devices, Rover, All products
Rover HD TAB 900 plus (SPECIAL OFFER)
Digital measurements: digital power, MER, BER, PER, LDPC, BCH, noise margin, MER versus CARRIER
Analog and image measurements: Analog level, V / A ratio
Power range, measurements: TV 28 to 130 dBμV, SAT 30 to 130 dBμV
Net-id on board: Net-id, NID, TSID, LCN, SAT orbit position
Fast spectrum with MAX HOLD: full spect. capabilities with memory peak, variable range and automatic reference level
Constellation: for TV / CATV and SAT signals
Echoes, Pre-echoes, Micro-echoes: Real-time representation
Quality: digital car quality test: PASS-MARGINAL-FAIL
Digital images: MPEG2-4 SD & HD images with program list, audio video PIDs, LCN, Video bit Rate all on one screen
TV memory plan: Countries around the world with pre-stored related channel plans
SAT Memory Plan: More than 2,000 transponders preemember for the world satellite
Manual memory plan: Programmable TV, SAT (or combined TV / SAT) PC or local keyboard
Loggers: TV, SAT & combined with stop & go function
Optical Power meter: with SC connector for fiber optic testing (FTTH & FTTX)
Free SMART PC interface program and FW upgrades
9 ”TFT TOUCH display: 16: 9 high resolution
Battery: Li-Po battery, 3 hours duration & Battery test function
USB PC interface: For online SW upgrade and memory plan management
USB PC interface: For memory stick
Housing: Metal box and elite bag. Optional bag
SKU: n/a
Other, Measuring devices, All products
Megasat Satmeter Digital 1 HD
Satfinder DVB-S and S2
Color screen: 3.5 ″ (8.9 cm) TFT LCD
Frequency: 950 - 2150 MHz
DiSEqC 1.0 / 1.1 / 1.2 / USALS
Unicable fit (EN 50494 and EN 50607)
LNB power supply: 13/18 V, max. 400 mA
LNB short-circuit and protection
Spectrum and constellation
Internal memory for data measurement
Search mode: Automatic, manual, Blind Scan
Automatic Satellite Detection (NIT)
Calculation of turn and tilt angle of the antenna (azimuth / elevation)
SKU: A7163
Measuring devices, Rover, All products
Rover HD TAB 700 Plus
Frequency Range: TV and CATV TUNER, extended band, 4-1250 MHz; SAT TUNER, extended band, 930-2,610 MHz; GSM extended band, 860-1,000 MHz for telephone repeater installation
Input Impedance: 75 ohm (interchangeable “F” connector)
Digital Measurements: Digital Power, MER, BER, PER, LDPC, BCH, Noise Margin, MER versus CARRIER
Analog Measurements & Picture: Analog level, V / A ratio
Power range Measurements: TV 28 to 130 dBμV, SAT 30 to 130 dBμV
Net-id on board: Net-Id, NID, TSID, LCN, SAT Orbit Position
Fast spectrum with MAX HOLD: full spectrum capabilities with memory peak, variable span and automatic reference level
Constellation: for TV / CATV and SAT signals
Echoes, Pre-echoes, Micro-echoes: Representation in real Time
Quality: Digital Auto quality Test: PASS-MARGINAL-FAIL
Digital Pictures: MPEG2-4 SD & HD pictures with Program List, Audio Video PIDs, LCN, Video bit Rate all on one screen
TV Memory plan: World Wide countries with related channels plans pre-memorized
SAT Memory Plan: More than 2,000 transponders prememorized for world wide Satellite
Manual Memory Plan: Programmable TV, SAT (or combined TV / SAT) by PC or Local Keyboard
Loggers: TV, SAT & combined with stop & go function
Optical Power meter: with SC connector for fiber optic testing (FTTH & FTTX)
Free SMART PC interface program and FW upgrades
7 ”TFT TOUCH display: 16: 9 high resolution
DC voltage at RF input: 5 - 12 - 18 - 24 V, DiSEqC, SCR and dCSS
Battery: Li-Po battery pack, 2 h duration
Power supply & Battery charger: 12 Vdc, 1A
USB PC Interface: For SW upgrade and memory plan management
USB PC Interface: For storage memory stick
Housing: Metal box and Elite bag
SKU: n/a
Measuring devices, Rover, All products
Rover QAM Expert / Prime Digital QAM Expret
DIGITAL CATV ANALYZER WITH ADVANCED FUNCTIONS
Frequency band between 44 and 1000 MHz
Input impedance: 75 Ohm (interchangeable “F” connector)
Signal strength measurement: 10 to 100dBuV; 120dBuV with external attenuator Fast spectrum with MAX HOLD: Full spectrum with peak storage; variable resolution with automatic reference level
NEW C / N measurement in analog mode (from SW 1.11)
FAIL - MARGINAL - PASS signal quality evaluation: Measurement of level or power simultaneously for up to 140 analog and digital channels in groups of 8 channels each
BARSCAN function for specific representation of analog and digital TV signals: from 10 to 100 channels with evaluation of the linearity of cable networks
Memory plan for various predefined or manually edited TV norms and standards
SKU: A1002457
Measuring devices, Rover, All products
ROVER HD TAB 5 ULTRA
Exclusive patented ROVER AUTODISCOVERY system: auto-matically detects and selects analog and digital COFDM / QAM TV signals in both measurement and spectrum mode.
Automatically identifies all the signals with digital modulation SAT, TV and CATV.
Automatic Assistant: Signal Quality analysis, Channel Scan memorization.
Barscan TV & CATV function from 10 to 100 channels on one screen.
Buzzer & Noise Margin real time graph for digital signals microinterruptions.
Reflectometric measurements APP.
SATELLITE: DiSEqC, SCR, dCSS & Motorized antenna commands, SAT FINDER & SAT EXPERT.
Custom Channel Plans: 25 (199 ch. Per plan), Programmable TV, SAT (or combined TV / SAT) by PC or Local Keyboard.
Loggers: TV, SAT & combined with stop & go function.
SAT Memory Plan: More than 2,000 transponders prememorized for world wide Satellite.
SPECIFICATIONS: MEASUREMENTS, SPECTRUM ANALYSIS & PICTURES
Frequency Range: TV, CATV & Radio: 30-1,000 MHz; SAT: 700–2,700 MHz.
Frequency Resolution: TV & CATV 25 KHz; SAT: 5 MHz.
Power range Meas .: TV 35 to 115 dBμV, SAT 5 to 105 dBμV.
Digital Meas: Digital Power, MER (36 to 40 dB max depending on modulation), BER, PER, LDPC, BCH, Noise Margin, MER versus CARRIER
SKU: n/a
Optical Equipment
Optical equipment, Global Invacom, All products
OTX Invacom LNB offset optical kit
INVACOM GLOBAL FIBER KIT IRS OTx 1310nm (optional on order 1550 nm)
REPLACEMENT FOR TRADITIONAL FIBER LNB
LNB FIBER REPLACEMENT KIT (925004),
COMPLETE KIT - DELIVERED WITH: LNB, OTx and PSU 20V
TWO BROADBAND ENTRIES FOR LNB
AN INPUT FOR UHF
SKU: L7713
Optical equipment, Global Invacom, All products
GI-FibreIRS Quad GTU MKIII
The FibreIRS GTU converts optical power to RF power (4 satellite bands and FM, DAB, DTT). All units have built in AGC which allows a wide dynamic range of optical powers without affecting output power and quality. Two LED indicators allow the user to monitor the status of the unit.
Quad for use directly with a STB / faceplate.
Can be powered via the satellite outputs and used with either the Optical LNB or the ODU32.
Features
Optical to RF converter (Satellite and FM, DAB, DTT)
Quad and Quatro versions available
Automatic Gain Control (AGC)
Powered by STB or PSU
Terrestrial signals overlaid onto each output (Quad only)
Frequency Morphing Technology (FMT) for Worldwide use
Optional whit circular polarization (D000187-CP)
SKU: n/a
Optical equipment, Global Invacom, All products
GI - 16 WAY FIBER IRS GTU EXPANDER MK3
The GTU Expander can increase the output from a Quatro GTU from 8 to 48 outputs (when using 3x 16 way expanders in cascade). Its unique design allows it to be connected directly to the Quatro GTU without using additional cables. Feature the capability of cascading three units and achieving a 50m drop.
Expands Quatro GTU output from 8 to 48 points
Unique design for direct attachment to Quatro GTU
Cascade up to 3 expanders
Expander and GTU Powered by single 20V PSU
Small form factor
SKU: n/a
Other, Optical equipment, All products
Triax TVC 06 - Mini Quad Re-converter
The TVC 06 is a mini optical-to-coax converter, which converts the frequency stacked optical signal provided from an Opto-LNB TOL or a TOU232-Kit (IRS 1) sidecar unit into four switched universal coax signals like a Quad LNB. The converters also provide a coax DTT / DAB / FM signal diplexed onto each output when it is inserted into the optical transmitter TOU 232 SA.
Built in AGC which allows a wide dynamic range of the optical signals on Fiber input with
less deviation of the RF output level and signal quality.
Two LED indicators display operational status.
Easy mounting via a wall baseplate.
Power supply via RF outputs from SAT receivers
Optional external power supply for continuous operation available.
Optical budget for PON (max.) 19.0 (@TOL 32, TOU 232) - 22.0 (@TOL 64) dB
Optical input power -12.0 to 0.0 @ TOL32, TOU232 / -13.5 to 0.0 @TOL 64 dBm
Optical splitting in PON (max.) 32 (@TOL 32, TOU 232) - 64 (@TOL 64)
CHARACTERISTICS
AGC (Automatic Gain Control) 30 dB
Output level SAT 75 dBµV
Output level TER 65 dBµV
Vertical High band (1.95 to 3.0 GHz) 1100… 2150 (> 14.5V 22KHz) MHz
Vertical Low band (0.95 to 1.95 GHz) 950… 1950 (> 14.5V) MHz
Wavelength 1310/1550 nm
Horizontal High band (4.4 to 5.45 GHz) 1100… 2150 (> 15.5V 22KHz) MHz
Horizontal Low band (3.4 to 4.4 GHz) 950… 1950 (> 15.5V) MHz
FREQUENCY
RF frequency range, horizontal polarities 3.4… 5.45 GHz
RF frequency range, vertical polarities 0.95… 3.0 GHz
TER frequency range DAB 174… 241 MHz
TER frequency range DTT 470… 854 MHz
TER frequency range FM 87… 108 MHz
RETURN LOSS
Return Loss 10 dB
electricity
Impedance 75 Ω
OPERATIONAL
DC Operating voltage 10… 20 VDC
PSU / adapter Art number 307657 (TPS323-20Vdc / 1.2A)
Temperature - operating -10… 60 ° C
DC Current consumption 125 (225mA @ 10V) mA
PSU / adapter INFO Optional
CONNECTORS
Optical Type Connector - FC / PC
IN Optical connector - FC / PC
F-female OUT connector (4xSAT + TER)
Output connectors 4xF (4 x SAT + TER)
SKU: C1003009
Optical equipment, All products, WISI
WISI 10G PON Carrier SFP + pluggable
This universal ITU-T XGS-PON or IEEE 10G EPON hot-pluggable SFP + Optical Transceiver provides a built-in 10G Ethernet-to-PON MAC bridge. It uses 10G CGS / EPON optics to enable 10G PON solutions at a fraction of the costs of fixed-format OLT chassis. This 10G OLT plugs into any commercially-available Ethernet port of any switch or networking equipment with SFP + sockets, enabling them to become part of any 10G PON network. The modularity and remote management capabilities of this SFP + OLT suits them ideally for virtualized PON solutions and Software Defined Network (SDN) implementations. This OLT enables service provider to quickly deploy high-bandwidth services in the most agile, elastic and scalable way. The space and power requirements are far less than any other OLT product on the market, including very high capacity deployments.
Features:
Hot-Pluggable SFP + footprint
Supports symmetric rates: 9.95G / 9.95G (XGS), 10.3G / 10.3G (10G EPON)
Supports 500 AllocIDs / T-CONTs (XGS)
1000 LLIDs (10G EPON)
Compliant with ITU-T G.9807.1 and G.988 specifications (XGS-PON)
Compliant with IEEE 802.3av, IEEE1904.1, and DPoE specifications (10G EPON)
IEEE AES encryption on PON side
Supports Phase / ToD transport: IEEE 1588v2 (XGS) IEEE 802.1as-to-IEEE 1588v2 (10G EPON)
Supports Synchronous Ethernet
Jumbo frames: 9.6KB (XGS)
12.5KB (10G EPON)
8M Byte of internal packet buffermemory with configurable priority queues
Class N2 (XGS) / PR30 + (10G EPON) optical power budget: 1577nm cooled EML DFB laser, 1270nm APD / TIA burst receiver
Integrated Digital Diagnostics and Monitoring (SFF-8472) over Two-Wire interface
Digital Receive Signal StrengthIndicator (RSSI)
Single fiber SC / UPC receptacle
SFI local interface
Enhanced jitter performance
Commercial or Enhanced case temperature.
Applications:
PON OLT Connectivity for Ethernet switches
Outside Plant PON access bridge connectivity
Wireless Backhaul
High ‐ Bandwidth business PON connectivity
Port ‐ by ‐ port expansion of existing switches
MDU ‐ located PON bridge
High ‐ Density PON aggregation
Data Center PON
SKU: n/a
Optical equipment, Global Invacom, All products
GI FibreIRS GTU Quatro MK III
The GI FibreIRS Quatro GTU Mk3 converts optical power to RF power (FM, DAB, DTT and 4 satellite bands).
Key features:
Optical to RF converter (Satellite and FM, DAB, DTT)
Automatic Gain Control (AGC)
Powered by Multiswitch or PSU (available separately)
Frequency Morphing Technology (FMT) for Worldwide use
The FibreIRS GTU converts optical power to RF power (4 satellite bands and FM, DAB, DTT). All units have built in AGC which allows a wide dynamic range of optical powers without affecting output power and quality. Two LED indicators allow the user to monitor the status of the unit.
Quatro for use with a multiswitch as it has dedicated outputs for each of the satellite bands (Vertical Low, Horizontal Low, Vertical High, Horizontal High) and terrestrial.
Can be powered via the satellite outputs and used with either the Optical LNB or the ODU32.
Optional whit circular polarization (D000288-CP)
SKU: C100182
Optical equipment, Global Invacom, All products
GI - 8 WAY FIBER IRS GTU EXPANDER MK3
The GTU Expander can increase the output from a Quatro GTU from 8 to 24 outputs (when using 3x 8 way expanders in cascade). Its unique design allows it to be connected directly to the Quatro GTU without using additional cables. Feature the capability of cascading three units and achieving a 50m drop.
Expands Quatro GTU output from 8 to 24 points
Unique design for direct attachment to Quatro GTU
Cascade up to 3 expanders
Expander and GTU Powered by single 20V PSU
Small form factor
SKU: n/a
Optical equipment, Global Invacom, All products
Fiber optic cable
Fiber optic cable with outer diameter 3mm, protected with steel sheath;
Equipped with FC / PC terminal connectors at both ends;
According to ITU-T G657A-LSZH;
Available lengths: 200m / 100m / 75m / 50m / 40m / 30m / 20m / 15m
The price can increase for lengths of: 10m / 3m / 1m;
Suitable for indoor and outdoor use;
Operating temperatures -40 ° C… + 60 ° C.
The displayed price is for 1 linear meter.
SKU: n/a
News and Information
EdgeQAM for non-linear (VoD) and linear TV applications
6 June 2022
We are in 2022 a year with new hopes and expectations. 2022 follows the years 2021 and 2020, years
Golden Media Wizard HD VOTE 4
25 February 2022
In these times, the pandemic has affected many areas, including equipment
GOLDEN INTERSTAR HD FTA S2
10 January 2022
The model we want to present to you in the following is Golden Interstar HD FTA S2 Plus
