HH mounts (DiSEqC antenna motors)
Showing all 2 results
-
Actuators, positioners, H-H mounts, HH mounts (DiSEqC antenna motors), All products
ACTUATOR H-H PREM.X 120CM (Timbru verde 1 leu)
Actuators, positioners, H-H mounts, HH mounts (DiSEqC antenna motors), All productsACTUATOR H-H PREM.X 120CM (Timbru verde 1 leu)
- PremiumX DiSEqC 1.3 PXM-S motor with steel gear.
- The Sat PremiumX DiSEqC 1.2 engine facilitates the movement of the antenna to different satellites up to a satellite antenna size of 120 cm. It is controlled by a receiver with Diseqc 1.2 or 1.3 without additional power supply and has 100 satellite positions. The steel gear and the stable structure of the engine ensure a longer life and stability.
- The power supply is provided by the receiver, which passes power through the coaxial cable and thus supplies power to the motor.
- Protocol: DiSEqC 1.2 and go to "X"
- Compatible receivers: Receiver with DiSEqC function 1.2
- Antenna size: Max 120cm
- Speed: 2.5 ° / sec (at 13V); 3.2 ° / sec (18V).
- Azimuth angle: 80 ° East ~ 80 ° West (160 °)
- Elevation: 25 ~ 75 °
- Input voltage: 13/18 V
- Output voltage: 13/18 V
- Power consumption: 100mA (standby) / 200mA (normal) / 350mA (max.)
- Satellite positions: 100 positions
- Calibration function: Yes, "GO TO X" (go to 0 °)
- East / West manual buttons: Yes, at the bottom
- Limitation protection: 1. Fixed by microswitch, 2. Programmable software limit, 3. Current limit
- Positioning sensor: High resolution Hall effect sensor
- Connection: F connection.
- Weight (engine): 3.1 kg (net) / 3.5 kg
- Dimensions (motor): 345 x 168 x 110mm
SKU: A7637 -
Actuators, positioners, H-H mounts, HH mounts (DiSEqC antenna motors), All products
Mount HH STAB 90
- Communication Protocol DiSEqC1.2
- Antenna Maximum Diameter 95 cm
- Maximum Antenna Weight 10 kg
- Support Pole Diameter 35 ÷ 68 mm
- Mobile Pin Length 145 mm
- Mobile Pin Diameter 42 mm
- Rotation Angle ± 65 °
- Rotation Speed 2.4 ° / s (18 V); 1.5 ° / s (13 V)
- Work Voltage 13/18 Vdc
- Stand-by Consumption 40 mA
- Work Absorption 180 mA
- Max Consumption 350 mA
- Operating Temperature -40 ° C ÷ + 80 ° C
- Max Relative Humidity 100%
- Settable Positions (DiSEqC1.2) 49 satellites
- Preset Positions (DiSEqC1.2) 28 satellites
- Settable Positions (USALS) without limits
- F-type connectors
- Coaxial cable link
- Mechanical Limits ± 70 °
- Settable Electronic Limits 5 ° ÷ 65 °
- Fine Rotation 0.1 ° pulses
- Rotation of the Rotor on the Pole 10 ° ÷ 70 °
- Weight 2600 g
SKU: 6fd86e0ad726
