- Frequency Range: TV and CATV TUNER, extended band, 4-1250 MHz; SAT TUNER, extended band, 930-2.610 MHz; GSM extended band, 860-1.000 MHz for telephone repeater installation
- Input Impedance: 75 ohm (interchangeable “F” connector)
- Digital Measurements: Digital Power, MER, BER, PER, LDPC, BCH, Noise Margin, MER versus CARRIER
- Analog Measurements & Picture: Analog level, V/A ratio
- Power range Measurements: TV 28 to 130 dBμV, SAT 30 to 130 dBμV
- Net-id on board: Net-Id, NID, TSID, LCN, SAT Orbit Position
- Fast spectrum with MAX HOLD: full spectrum capabilities with memory peak, variable span and automatic reference level
- Constellation: for TV/CATV and SAT signals
- Echoes, Pre-echoes, Micro-echoes: Representation in real Time
- Quality: Digital Auto quality Test: PASS-MARGINAL-FAIL
- Digital Pictures: MPEG2-4 SD & HD pictures with Program List, Audio Video PIDs, LCN, Video bit Rate all on one screen
- TV Memory plan: World Wide countries with related channels plans pre-memorized
- SAT Memory Plan: More than 2.000 transponders prememorized for world wide Satellite
- Manual Memory Plan: Programmable TV, SAT (or combined TV/SAT) by PC or Local Keyboard
- Loggers: TV, SAT & combined with stop & go function
- Audio: AAC supplied, DOLBY (opt.)
- Optical Power meter: with SC connector for fiber optic testing (FTTH & FTTX)
- Free SMART PC interface program and FW upgrades
- 7” TFT TOUCH display: 16:9 high resolution
- DC voltage at RF input: 5 – 12 – 18 – 24 V, DiSEqC, SCR and dCSS
- Battery: Li-Po battery pack, 2 h duration
- Power supply & Battery charger: 12 Vdc, 1A
- USB PC Interface: For SW upgrade and memory plan management
- USB PC Interface: For storage memory stick
- Housing: Metal box and Elite bag
- Weight: only 1,4 Kg
- Size: H 25,5 x W 13,0 x D 4,0 cm (meter only)
